*IMPORTANT NOTICE - Samsung MIM Controller required with heat pump*
Hot Water Temperature
The EHS Mono HT Quiet Heat Pump combines advanced features to achieve hot water temperature of 70°C and ensures that it is provided reliably. Enlarged Heat Transfer Area by approximately 11.9% larger to help exchange heat quickly. Strengthened Compression Parts by using Reed Valves. New Scroll Compressor with Flash Injection.
Low Noise
With the introduction of new technologies for noise reduction, the EHS Mono HT Quiet Heat Pump operates quietly with noise levels as low as 35 dB(A)7 using a 4-step Quiet Mode.
Multi-serration Fan reduces fan noise by minimizing the air vortex. 2-layered Insulation with Groove Grid Felt The 2-layered Insulation consists of Compression Felt on the compressor and an enclosure inside the cabinet, effectively blocks noise. The enclosure is made of a high-performance material with a patented Groove Grid Felt design, which absorbs the various noises produced by the compression parts and vibration. Spring Grommet for the Compressor Mounting absorbs the vibration produced by the compressor and minimizes the resulting noise. Reinforced Crankshaft in the Compressor reduces low frequency resonance noise. Quiet Mark Certificate The EHS Mono HT Quiet Heat Pump has received the Quiet Mark certificate. The Quiet Mark certificate is applicable for UK & EU territories only.
Energy usage
Our Samsung EHS Heat Pump includes a range of advanced technologies that help optimize your energy usage. The Samsung EHS Mono HT Quiet Heat Pump has a SCOP* of A+++ energy efficiency rating therefore it is proven to operate with a high level of efficiency. The Samsung EHS Mono HT Quiet Heat Pump achieves good heating performance at low temperatures by using the R32 refrigerant. This helps mitigate the depletion of the ozone layer and lower the impact of global warming as they reduce the amount of refrigerant needed and cut down on CO₂ emissions compared to conventional R410A refrigerant.
Durable & corrosion resistant
The Samsung EHS Mono HT Quiet Heat Pump outdoor unit features improved anti-corrosion capabilities on the heat exchanger and chassis to ensure maximum durability in harsh environments.
Based on internal testing, verified by TÜV Rheinland, in accordance with ISO 9227, ISO 14993 and ISO 21207 using specimens from the heat exchanger of an Samsung EHS Heat Pump outdoor unit. For more details, please contact your local Samsung representative.
Based on internal testing using corrosion chambers, Q-FOG and CCT-1100. The Complex Cycle Test (CCT) includes cycles of spray (for 2 hours at 35°C), dry (for 4 hours at 60°C with 30% Relative Humidity) and damp (for 2 hours at 50°C with 95% Relative Humidity) conditions. As a result, the Galvanized Iron Steel Plate (GI) formed red rust after 240 hours, which is 43% slower than general Electro-Galvanized Steel Plate (EGI) which forms red rust after 168 hours.
For example, if it has stopped operating for 60 minutes when the outdoor temperature is 3℃, the pump on the water pipe side is forcibly operated to prevent the water from freezing in the water pipe.
Based on internal testing on the Samsung EHS Mono HT Quiet Heat Pump outdoor unit compared to a conventional EHS outdoor unit.
Wi-Fi connection and Samsung SmartThings application account are required. Wi-Fi Kit to be ordered separately. Requires iOS 10.0 or later & Android 5.0 or later.
Durafin™ Ultra: An anti-corrosive layer and a hydrophilic layer disperses water and reinforces its corrosion-resistance, which was proven using the Salt Spray Test (SST) over a period of 3,000 hours. GI Steel Plate: The EHS Mono HT Quiet outdoor unit uses Galvanized Iron (GI) Steel Plate with a PE powder coating of up to 100μm thickness, which is proven to improve corrosion resistance by 43%, based on the Complex Cycle Test (CCT)12. So, it protects the cabinet from rusting and ensures it can endure harsh conditions
Antifreeze Protection features: Its Antifreeze Protection Control continuously monitors the operating status and the outdoor temperature, and prevents the water pipe from freezing by forcibly pumping the water after a certain period of time.
Enhanced Flash Injection Technology: The Flash Injection Technology increases the flow of refrigerant, and the position and size of an injection hole is optimally designed to maximize the refrigerant volume. So, even at -30°C it can supply hot water of up to 60°C for continuous comfort in the coldest conditions
Aesthetic design
The heat pumps premium dark colour allows for the Samsung EHS Mono HT Quiet Heat Pump to seamlessly blend into a building’s exterior. This outdoor unit is approximately 1m in height. So, it can be installed under a balcony window, enhancing the home interior as it does not affect the view out of the window,
